- 35,000+Components modelled
- 3,100Clashes resolved
- 1,800Isometrics extracted
- 5Disciplines modelled
The challenge
The client's expansion project needed a full 3D model built to its own specifications and catalogues, with clean data that could be handed over to operations.
Our scope
- Project setup, catalogues and specifications
- Equipment, piping, structural and E&I modelling
- Clash detection and resolution
- Isometric and MTO extraction
- Model data handover
Our approach
We configured the project catalogues first, then modelled all disciplines in one model. Navisworks clash runs were held weekly, with every clash tracked to closure before each model review.
- Weekly clash detection runs
- 30/60/90% review models
- Automated isometric extraction
The outcome
The model passed each review milestone with a falling clash count, and the handover dataset gave the operator a reliable digital record of the new unit.
Scope of work
- Catalogue setup
- 3D modelling
- Clash management
- Isometric extraction
- Data handover
